特性及應用：

CKF-A 為非接觸楔塊式單向離合器，內環旋轉。*內環被設計用于單向功能，無軸承支撐。

使用時必須 安裝軸承以*內環與外環的同心度。

當用于防止逆轉用途時必須檢查轉速不可低于超越轉速*低允許值，如下頁規格表中。

此型號主要用于高速工況下防止逆轉，亦可用于超運轉速度離合器之高速超越、低速楔合

的雙速驅動切 換裝置。

Characteristics and application:

CKF -a is non-contact wedge type one-way clutch, the inner ring spinning.Only the inner ring

is designed to one-way function, without the bearing support.Must be installed to ensure the

concentricity of the inner ring and outer ring of the bearing.When used to prevent reversal use must

check speed is lower than beyond its minimum value, the following pages specification table.This

model is mainly used for high speed working conditions to prevent reverse, can also be used in super

speed clutch of high-speed beyond, wedge double-speed drive at low speed change cutting device.
